Socket Weld Pipe Flange, Raised Face Socket Weld Flange

These pipe flanges are attached by inserting the pipe into the socket end and applying fillet weld around the top. This allows for a smooth bore and better flow of the fluid or gas inside of the pipe. The connection with the pipe is done with 1 fillet weld, at the outside of the flange. But before welding, a space must be created between flange or fitting and pipe.

Rated 4.7/5 based on 454 customer reviews
Share:
Content

Socket weld flange simplified as SW flange, it has a recessed area (like a shoulder) in the flange bore, this shoulder serves as a guide to set the depth of the pipe that inserted to the flange. Socket welding flange initially designed for high pressure small diameters piping system.

Face: Raised face,  Flat face,  RTJ facing.

These pipe flanges are attached by inserting the pipe into the socket end and applying fillet weld around the top. This allows for a smooth bore and better flow of the fluid or gas inside of the pipe. The connection with the pipe is done with 1 fillet weld, at the outside of the flange. But before welding, a space must be created between flange or fitting and pipe.

Applications



  • Water supply facilities
  • Food industrial pipelines
  • Chemical industrial pipelines
  • Electronic industrial pipelines
  • Air conditioning facility pipelines
  • Agriculture and garden production transportation
  • Pipeline network for solar energy facility
