Threaded Swage Nipple Carbon Steel Fittings

Threaded union is easy to install and disassemble so that it is popular in piping system.Threaded fitting used thread type to connect with pipes,threaded fittings have many pressures:2000,3000,6000.

Carbon Steel: ASTM A105 / A105N, ASTM A350 LF2/LF3, ASTM A694 F42 / 46 / 56 / 60 / 65, P235GH, P265GH, P280GH, P355GH
Alloy Steel: ASTM A182 F11 / 12 / 5 / 9 / 91 / 92 / 22
Stainless Steel: ASTM A182 F304/304L/304H, 316/316L, 321, 310S, 317, 347, 904L，1.4404, 1.4437.
Duplex Stainless Steel: ASTM A182 F51, F53, F44

Threaded couplings used thread connection to connect two pipes.Threaded coupling is belong to forged steel fittings.The other type of forged fitting is socket weld fittings.All the forged fittings are high pressure pipe fittings.

What is a Threaded Coupling,what about its specification and its advantages.

Shapes:
Equal：This is a Pipe fitting with the same size on three sides.
Reducing：The main pipe of these tee is different from the diameter of the branch pipe, and the diameter of the main pipe is larger than that of the branch pipe.

What is a treaded nipple,what about its specification and its difference between coupling.

Threaded Pipe Fittings Specification
Shape: Elbow,Tee, Cross, Coupling, Cap, Swage Nipple, Bushing, Plug, Nipple, Union, Hex Nipple,Threadolet.
Size Range: 1/8″ –  4″ / DN6 – DN100
Pressure Rating: Class 2000lbs, 3000lbs, 6000lbs
Thread Type: NPT, PT, BSPP, BSPT, PF
Standard: ASME B16.11, BS3799, EN 10241, MSS SP-83, MSS SP-97

What is a treaded nipple,what about its specification and its difference between coupling.

Threaded coupling is used to connect two pipes with threaded connection.Forged steel pipe fittings can divided into SW (socket weld) fittings and THD (threaded) fittings.

Half Coupling: One end of a half thread coupling is threaded and the other end is welded. Straight: It is a kind of pipe coupling with the same diameter at both ends. Reducing: The two ends of the coupling have different sizes

Forged threaded pipe fittings are named by its manufacturing forging process and produced according to ASME B16.11, MSS-SP-79\83\95\97 and BS3799 standards. It is a connector in between nominal bore pipes. Their material can be made of carbon steel A105 and stainless steel SS316 & 304.

Forged threaded elbows are very common in chemical, oil refining, petrochemical and other industries, and are also used in some other industries.

The main pipe of these tee is different from the diameter of the branch pipe, and the diameter of the main pipe is larger than that of the branch pipe.

Swaging nipples is divided into tubing sub and casing sub. Flanging nipple in pipe connection is commonly used with flange. Diameter pipe (reducing nipple) is a pipe fitting used for straight connection of two pipes with different sizes to realize pipe diameter reduction. There are concentric reducing joints and eccentric reducing joints

High pressure forged steel tee is used for providing branch, it can be divided into equal tee and reducing tee.High pressure tee is used for adding pipe branchs. An equal tee, otherwise called straight tee, means the branch diameter of this tee is same with the main pipe (Run pipe) diameter of this tee.

They have applications in many industries,including chemical processing, petroleum, refining, marine waste treatment, utilities / power generation, industrial equipment, natural gas compression and distribution industries. Tee pipe is also recommended for industrial equipment hydrodynamic system

Full Coupling: Both ends of the full thread coupling are threaded. Half Coupling: One end of a half thread coupling is threaded and the other end is welded.

Threaded Pipe Fittings Specification
Shape: Elbow,Tee, Cross, Coupling, Cap, Swage Nipple, Bushing, Plug, Nipple, Union, Hex Nipple,Threadolet.
Size Range: 1/8″ –  4″ / DN6 – DN100
Pressure Rating: Class 2000lbs, 3000lbs, 6000lbs
Thread Type: NPT, PT, BSPP, BSPT, PF
Standard: ASME B16.11, BS3799, EN 10241, MSS SP-83, MSS SP-97

ASME B16.11 is the standard of both socket-welding and threaded. Threaded fittings are available in pressure ratings Class 2000, 3000, and 6000;
Socket welding fittings are available in pressure ratings Class 3000, 6000, and 9000.

Steel pipe elbow can be divided into 3 types as buttweld, threaded, socket weld in accordance with connection.Threaded elbow is more convenient compare with the buttweld and socket weld elbow.

A combination of pipe nipples are recommended for low-pressure discharge and suction service for various compatible liquids and not for compressible products like air, nitrogen or steam.

Threadolet has the same basic design as a weldolet. The commonly used manufacturing standards of the branch stand include MSS sp-97, GB / t19326 and other standards.

ASTM A105 threaded fittings is commonly used carbon steel grade which is used to manufacture forge piping components such as forged fittings and flange of small diameter piping, generally for piping whose nominal diameter is NPS 2 or smaller.

The basic difference between couplings and unions in use is that couplings connect pipes to pipes or pipes to bends.Unions are used to connect and disassemble part of the piping system for maintenance or replacement.

Class 3000 threaded union is the most used pressure of threaded union.ASME B16.11 is the standard for forged fittings according to American Standard.

Steel tee is a T-shaped pipe fitting with three branch pipes. It is used to divide pipes to adjust flow and change direction.

What is a plug,what about its specification and its difference between a caps.

Weldolet, an economical butt-weld branch connection, is designed to minimize stress concentrations and provide integral reinforcement. manufactured to meet your specific reinforcement requirements.

Thread Types:

NPT  PT  BSPP  BSPT  PF
